HARTLEY OSCILLATOR TRAINER

HARTLEY OSCILLATOR TRAINER

Category: Electronics

Model No:IE- 901

Experimental Training Board has been designed specifically to study of Hartley Oscillator using transistors and other electronic components. The training board is complete in all respect except C.R.O. Practical experience on this set up carries great educative value for Science and Engineering Students.

Product Description

The Hartley oscillator is an electronic oscillator circuit in which the oscillation frequency is determined by a tuned circuit consisting of capacitors and inductors, that is, an LC oscillator. The circuit was invented in 1915 by American engineer Ralph Hartley.

Features:

  •     Tuned Circuit Diagram is printed on panel
  •      In built Power Supply

Scope of Learning:

  • To design and construct a Hartley oscillator and to measure its output frequency.

Technical Specifications:

  • Power Supply    :     + 12 V,/ 500mA

Capacitor

  •     Type           :     Gang Capacitor
  •     Value          :     Variable in pF

Circuit

  • Type                       :     Tuned LC Circuit
  • Mains                     :    230V AC ±10%,50Hz
  • Fuse                      :    500mA
  • Dimension             :    W 215 x D 195 x H130

Required Accessories :

  • Dual Trace DSO/ CRO 20MHz
