LATTICE DYNAMICS KIT

LATTICE DYNAMICS KIT

Category: Electronics

Model No:SP-LDK

Lattice dynamics is an essential component of any postgraduate course in Physics, Engineering Physics, Electronic Engineering and Material Science. In particular it is essential to understanding the interaction of electromagnetic waves and crystalline solids. In general, students find it difficult to understand involved concepts like ACOUSTICAL MODE, OPTICAL MODE, and ENERGY GAP etc, which they cannot see for themselves in the laboratory.

Product Description

It consists of an Audio oscillator with amplitude control and facility to vary the frequency from 0.9 KHz to 90 KHz. It has built in power supply and output stage to match the impedance of simulated lattice. Another part of Lattice Dynamic Kit consists of transmission line, which simulates one-dimensional mono-atomic and di-atomic lattices.

The only additional equipment needed is a General purpose C.R.O
Scope of Learning:

  • Study of the Dispersion relation for “Mono-atomic Lattice”. Determination of the Cut-off frequency and Comparison with theory.
  • Study of the Dispersion relation for the Di-atomic Lattice, Acoustical mode and Energy Gap. Comparison with theory.

Technical Specifications:

Audio Oscillator

  •     Range           :    0.9KHz to 90 KHz
  •     Amplitude      :    Variable by Knob
  •     Display          :    7 segment LED

Power supply

  • Voltage              :    12V In built
  • Input Mains        :    220-230V AC 50Hz
  • Weight                :    20 Kg Approx
